The SHIMANO DEORE XT M8120 caliper features consistent braking performance and reliable stopping power in all conditions. The 4-piston caliper instills greater downhill confidence and control.
FEATURES
Superior modulation gives you greater control
Quicker Piston retraction
High braking power instills greater downhill confidence and control
Reduces disc brake rotor wobbling noise and increases braking power by 10% (vs. M8000)
Four Piston
Quick and easy assembly
Banjo type connection and inside hose routing
PRODUCT SPECIFICATIONS
MODEL NO
BR-M8120
SERIES
DEORE XT M8100 Series
Color
Series color
Average weight
141
Brake type
Hydraulic disc brake
Brake hose (Kit)
SM-BH90-SBM
Hose joint
Banjo
Brake hose color (kit)|1
Black
J-Kit spec (for OEM)
✔
ICE TECHNOLOGIES pad compatible caliper
✔
Pad|Standard 1
N03A-RF Resin (w/ fin)
Pad|Standard 2
N04C-MF Metal (w/ fin)
Pad|Option 1
D03S-RX Resin (w/o fin)
Pad|Option 2
D02S-MX Metal (w/o fin)
Recommended brake lever
BL-M8100 BL-T8100
Recommended disc brake rotor
RT-MT800
Compatible Brake Rotor Size|140 mm (SS)
✔
Compatible Brake Rotor Size|160 mm (S)
✔
Compatible Brake Rotor Size|180 mm (M)
✔
Compatible Brake Rotor Size|203 mm (L)
✔
Compatible brake rotor size|220 mm (LL)
✔
Oil
SHIMANO mineral
Mount type
Post type
Piston
4
Caliper fixing bolt|Tool size
5 mm
Caliper fixing bolt|Anti loosen method
Snap ring
Pad mount
Pad axle
SHIMANO DEORE XT - Hydraulic Disc Brake Lever - I-SPEC EV Clamp Band
With a focus on reduced weight and cross-country tuned stopping power, the SHIMANO DEORE XT BL-M8100 lever provides intuitive modulation so that you can explore your limits with confidence.
FEATURES
Intuitive and versatile braking keeps your focus on the trail
Optimized lever axle position with additional contact point and refined ergonomics
Greater flexibility and action-optimized cockpit layout
I-SPEC EV
High rigidity
10% stiffer than M8000 even under high temp conditions
Quicker brake engagement with shorter free stroke
Rider tuned adjustment
Toolless reach adjust
Free stroke adjust
PRODUCT SPECIFICATIONS
MODEL NO
BL-M8100
SERIES
DEORE XT M8100 Series
Color
Series color
Average weight
105
Brake type
Hydraulic disc brake
Lever size (finger)
2
Brake hose (Kit)
SM-BH90-SBM
Hose joint
Straight
Brake hose color (kit)|1
Black
J-Kit spec (for OEM)
✔
SERVO WAVE
✔
Reach adjust|Toolless
✔
Free stroke adjust
✔
Compatible shift lever mount|Clamp band
✔
Compatible shift lever mount|I-SPEC EV
✔
Clamp band|Open clamp
✔
Shift lever rotation angle adjust range (I-SPEC EV ; deg.)
